- Operator controls:
- Power Supply:
- Operating Voltage: 7-35 VDC
- Standby Current: 25 mA (typical)
- (4) Resistive (OEM/application specific)
- (2) Low-side (–DC), 250mA Max (OEM/application specific)
- (1) CAN: J1939
- Enclosure Material: High impact ABS, epoxy filled
- Dimensions (WxHxD): (w x h x d): N/A
- Weight: 0.13 lb (.6 kg)
- IP rating: IP65 case (with DIP switch protective film intact), exposed lead ends
- Relative Humidity: N/A
- Operating Temperature: -40° to +85°C (-40° to 185°F)
- Storage Temperature: -40° to +85°C (-40° to 185°F)
- Vibration: N/A
- Shock: N/A
- EMI/EMC: 2004/108/EC
- J1113-11 pulses 1c, 2a, 3a/b and 5a
- EN 61000-4-2 ESD
- EN 61000-4-3 Radiated disturbance
- EN 61000-4-4 Fast transients
- EN 61000-4-5 High energy transients
- EN 61000-4-6 Conducted RF disturbance
- CISPR 16-1-2, 4.3 Conducted Emissions
- CISPR 16-2-3 Radiated Emissions
