Interface:
- N/A
-
Operator controls:
- N/A
-
Power Supply:
- Operating Voltage: 7-35 VDC
- Standby Current: 25 mA (typical)
-
Inputs:
- (3) Resistive (240-33.5 Ohms, 240-30 Ohms, 10-180 Ohms)
- Outputs:
- N/A
-
Communications:
- (1) CAN: J1939
- Physical/Environmental:
- Enclosure Material: High impact ABS, epoxy filled
- Dimensions (WxHxD): (w x h x d): N/A
- Weight: 0.13 lb (.6 kg)
- IP rating: IP65 case (with DIP switch protective film intact), exposed lead ends
- Relative Humidity: N/A
- Operating Temperature: -40° to +85°C (-40° to 185°F)
- Storage Temperature: -40° to +85°C (-40° to 185°F)
- Vibration: N/A
- Shock: N/A
-
EMI/EMC: 2004/108/EC
- J1113-11 pulses 1c, 2a, 3a/b and 5a
- EN 61000-4-2 ESD
- EN 61000-4-3 Radiated disturbance
- EN 61000-4-4 Fast transients
- EN 61000-4-5 High energy transients
- EN 61000-4-6 Conducted RF disturbance
- CISPR 16-1-2, 4.3 Conducted Emissions
- CISPR 16-2-3 Radiated Emissions
